SIMATIC IPC PX-39A PRO
Operating Instructions, 11/2022, A5E51699950-AA
113
Hardware description
A
A.1 Motherboard
A.1.1 Layout of the motherboard
The motherboard consists of these main components: Processor and chip set, one slot for the
memory module, internal and external interfaces and the flash block for the BIOS.
①
Slot for memory module
②
Slot for M.2 NVMe SSD in the device
③
Slot for expansion module (M.2)
④
Backup battery
Technical features of the motherboard
Technical features of the motherboard can be found under "Technical specifications of the
motherboard (Page 92)".
