Installing and connecting the device
3.2 Installing the device
SIMATIC IPC BX-39A
Operating Instructions, 07/2022, A5E50715883-AA
29
3.2 Installing the device
3.2.1 Mounting types
Note
Ensure that the required minimum clearance to other components or enclosure panels is
maintained.
With horizontal mounting position:
Underneath at least 100 mm
Above at least 50 mm
At least 50 mm at the side
With vertical mounting position and portrait mounting:
Underneath at least 50 mm
Above at least 50 mm
At least 50 mm at the side
Note
Observe the permitted temperature range for operation of the device in the respective
mounting position as defined in section "Technical specifications (Page 74)".
