Mounting and connecting the device
3.2 Mounting the device
SIMATIC IPC PX-39A PRO
48 Operating Instructions, 11/2022, A5E51699950-AA
3. Grease the round tube adapter ⑦ or 48.3 mm round tube ⑧ with grease suitable for NBR
seals, and insert the round tube adapter ⑦ or 48.3 mm round tube ⑧ into the
corresponding opening of the PRO device.
Make sure that the sealing ring (O-ring) is not damaged. Fasten the round tube with the 2
setscrews ⑥ M8x10 from the accessory kit.
Observe the appropriate torque:
– Siemens round tube adapter ⑦: 8 Nm
– 48.3 mm round tube of steel ⑧: 8 Nm
– 48.3 mm round tube of aluminum ⑧: 5 Nm
NOTICE
48.3 mm round tube ⑧
For the device to not loosen and drop in case of vibrations, the round tube must offer a
groove into which the setscrews can be fitted.
Otherwise the device can become loose due to vibrations and drop.
4. If an adapter plate for the Siemens round tube adapter is included with your support arm,
attach the adapter plate to the support arm with 4 M6x12 screws.
Observe the torque that is specified for the support arm.
5. Insert all connection cables through the opening of the round tube adapter or 48.3 mm
round tube into the connection compartment of the PRO device.
Make sure that the connecting cables are not damaged.
6. Attach the device with 4 M6 screws, 16 mm to 20 mm long, to the support arm from below.
The screws are not included in the product package of the PRO device.
Observe the torque that is specified for the support arm.
Make sure that all connecting cables are fed through the round tube adapter into the
interior of the device without damage.
