Mounting and connecting the device
3.1 Preparing for mounting
SIMATIC IPC PX-39A PRO
Operating Instructions, 11/2022, A5E51699950-AA
39
3.1.4 Operating positions
The following operating positions are permitted for the PRO devices.
• Standard operating position: Vertical installation in horizontal format
• Inclined installation in horizontal format with a vertical inclination of maximum ±45 °
The vertical installation in upright format is prohibited for the PRO device.
Note
To ensur
e heat dissipation of the device, keep at least 5 cm distance between the device and
neighboring walls or other devices/machines and make sure that there is adequate air flow.
Device version prepared for pedestal/extension components (flange at bottom)
Operating po-
sition
Deviation from the vertical
①
Inclined
≤ 45°
②
Vertical
0°
