Product description
1.6 System components
SIMATIC IPC PX-39A PRO
20 Operating Instructions, 11/2022, A5E51699950-AA
1.6.2 Round tube adapter
Round tube adapter for device version "prepared for support arm and extension components"
An optional round tube adapter that is not included in the product package is available for
the device version "prepared for support arm and extension components".
The round tube adapter converts the round tube connection into a mechanically compatible
interface to the base adapter. The flange of the round tube adapter has the same drilling
pattern as the base adapter. This means you can use all couplings of the support arm or
pedestal systems with mechanical interface for the base adapter.
Ring groove for fastening on PRO device with setscrews
Mechanical interface to support arm
Article number of the round tube adapter: 6AV7674-1KF00-0AA0
