Installing and connecting the device

3.3 Connecting the device

SIMATIC IPC BX-39A

Operating Instructions, 07/2022, A5E50715883-AA

Requirements

• The device has been installed.

• The protective conductor (Page 38) is connected.

• 1 wired terminal (Page 39).

The corresponding 24 V DC power supply is off.

• 1 0.6 × 3.5 mm Philips screwdriver

Procedure

Insert the terminal at the marked po-

sition.

Secure the terminal using the inte-

grated screws.
