Product description
1.4 External design of the device
SIMATIC IPC RW-543A
12 Operating Instructions, 03/2023, A5E52332059-AA
1.4 External design of the device
1.4.1 Front panel
①
Front left door
⑥
Front right door
②
Lock
⑦
Connections for USB 2.0 devices,
compatible with USB 1.1
③
On/off button
⑧
HDD status display
④
Connection for USB 2.0 devices,
compatible with USB 1.1
⑨
Power status display
⑤
Drive bays 3 x 5.25"
1.4.2 Rear of the device
