Siemens SIMATIC IPC RW-543A User Manual

Technical specifications
8.5 Ambient conditions
SIMATIC IPC RW-543A
80 Operating Instructions, 03/2023, A5E52332059-AA
8.5 Ambient conditions
See the note in "Applicability of technical specifications (Page 75)".
Climatic ambient conditions
Temperature
Tested according to IEC 60068-2-2; IEC 60068-2-1; IEC 60068-2-14
Operation +5 °C to +40 °C
Gradient: ≤ 10 K/h; no condensation
Storage/transport –20 °C to +60 °C
Gradient: ≤ 20 K/h; no condensation
Relative humidity
Tested according to IEC 60068-2-78; IEC 60068-2-30
Operation
5% to 85%; no condensation
Gradient: ≤ 10 K/h; no condensation
Storage/transport
5% to 95%; no condensation
Gradient: ≤ 20 K/h; no condensation
Atmospheric pressure
Operation
1013 to 795 hPa,
corresponds to an altitude of 0 m to 2000 m
Storage/transport
1013 to 660 hPa,
Corresponds to an altitude of 0 m to 3500 m
Mechanical ambient conditions
Vibration
Tested according to IEC 60068-2-6;
Operation
With HDD: 10-58 Hz: 0.015mm; 58-200 Hz:1.96 m/s2; 10 cycles
With SSD: 10-58 Hz: 0.0375mm; 58-200 Hz:4.9 m/s2; 10 cycles
Storage/transport
5 to 8.4 Hz, amplitude 3.5 mm; 8.4 to 500 Hz: 9.8 m/s2
Resistance to shock
Tested in accordance with IEC 60068-2-27
Operation With HDD: Half-sine: 9.81 m/s2, 20 ms, 3 shocks per axis
With SSD: Half-sine: 150 m/s2, 11 ms, 3 shocks per axis
Storage/transport
Half-sine; 250 m/s
2
; 6 ms; 1000 shocks per axis
Special features
Quality assurance
In accordance with ISO 9001
Altitude of operation (m)
Up to 2000 m
8.6 Technical specifications of the drives
See the note in "Applicability of technical specifications (Page 75)".
Information on the drives is available in your order documents.
Drive
Maximum number of drives
Types of drive
HDD
2 (depends on the selected
configuration)
• 3.5" SATA, 6 GB/s; 1 TB
SSD
1
• 256 GB
• 512 GB
