Siemens SIMATIC IPC RW-543A User Manual

Technical specifications
8.7 Technical specifications of the motherboard
SIMATIC IPC RW-543A
Operating Instructions, 03/2023, A5E52332059-AA
81
8.7 Technical specifications of the motherboard
See the note in "Applicability of technical specifications (Page 75)".
Chipset
Intel® Q470 Chipset PCH
Processor
• Intel® 10th Generation Core / Pentium Desktop CPU, LGA1200
Slots for memory modules
4 x Non-ECC UDIMM slots for DDR4 2400/2666/2933MHz, up to 128GB
Main memory
4 up to 128 GB, DDR4 SDRAM PC4-3200T
Power consumption per PCIe slot with
x4 expansion card, maximum
permitted
• 3.3 V / 3 A
• 12 V / 2.1 A
• 3.3 V
aux / 0.4 A
Power consumption per PCIe slot with
x16 expansion cards, max.
permissible
• 3.3 V / 3 A
• 12 V / 5.5 A
• 3.3 V
aux / 0.4 A
Max.permitted power consumption
per PCI slot (5V,32-bit)
5V, 5A or 3.3 V, 7A; 12V 0.5A; 3.3 Vaux 0.4A
PCI modules with exclusive 5 V supply
≤ 25 W
Power loss per slot with max. ambient
air temperature 40 °C, permissible
≤ 25 W
Power loss of all PCI and PCIe slots
with max. ambient air temperature
40 °C, permissible
≤ 100 W
In sum, the current for 3.3 Vaux may not exceed 1.2 A.
8.8 Technical specifications of graphic
See the note in "Applicability of technical specifications (Page 75)".
Graphic controller
Intel® HD Graphics, 3D engine (integrated in processor)
Graphics memory
Dynamic Video Memory Technology, uses 32 MB and 1.7 GB RAM in main memory
Resolutions/frequencies/colors
• HDMI up to 4096 x 2160@30Hz
• VGA up to 1920 x 1200@60Hz
• DVI-D up to 1920 x 1200@60Hz
