Siemens SIMATIC IPC RW-543A User Manual

BIOS description
11.2 Main menu
SIMATIC IPC RW-543A
Operating Instructions, 03/2023, A5E52332059-AA
95
Navigation key
The Aptio
TM
TSE keyboard-based navigation can be accomplished using a combination of the
keys, for example, function keys, Enter, ESC, ARROW keys. Function description for
navigation keys is listed below.
Press
To
→ ← : Select Screen
Menu Bar and select a BIOS setup page, for example, the Main menu.
↑ ↓/Click : Select Item
Select a BIOS setup item or sub page.
Enter/Dbl Click : Select
Select an option to edit its value or access a sub menu.
F1 : Change Opt.
Change the field value of a particular setup item, for example, date, time.
F2 : General Help
Display the general help window.
F3: Previous Values
Enable user to load previous values in BIOS setup Menu.
F9: Optimized Defaults
Enable user to load optimized default values in BIOS Setup Menu.
F10: Save & Exit
Enable user to save the current configuration and exit BIOS Setup Menu.
F11: Print Screen
Enable user to print screen.
ESC/Right Click: Exit
The <ESC> Key or Right Click allows you to discard any change have made and exit BIOS
setup menu.
Configuration fields
Configuration fields show the values for the menu items. If an item is user-configurable, you
can change the value of the field opposite the item. You cannot select an item that is not user
configurable.
A configurable field is enclosed in brackets, and is highlighted when selected. To change the
value of a field, select it and press Enter to display a list of options.
Menu items
Menu items are system parameters in each page and vary according to different menu pages.
11.2 Main menu
The Main menu
The Main menu provides you an overview of the basic system information, and allows you to
set the system date and time.
Note
Take the BIOS version installed on your IPC as standard.
