Expanding and assigning parameters to the device
6.3 Memory modules
SIMATIC IPC RW-543A
Operating Instructions, 03/2023, A5E52332059-AA
53
5. Loosen the bracket by unscrewing its screw ① and place it ② on the expansion card.
6. Secure the bracket.
7. Close the device.
6.3 Memory modules
6.3.1 Usable memory modules
Dual channel memory
The motherboard provides four DDR4 memory sockets and supports dual channel technology.
The memory capacity of the device can be upgraded to a maximum of 128 GB.
The table below shows the supported memory types of motherboard.
Module type
Module Size
Description
DDR4‐SDRAM
4 GB
DDR4-2400/2666/2933MHz-UDIMM-288pin
DDR4‐SDRAM
8 GB
DDR4-2400/2666/2933MHz-UDIMM-288pin
DDR4‐SDRAM
16 GB
DDR4-2400/2666/2933MHz-UDIMM-288pin
