Siemens SIMATIC IPC RW-543A User Manual

Markings and symbols
C.5 Interfaces
SIMATIC IPC RW-543A
Operating Instructions, 03/2023, A5E52332059-AA
135
C.5 Interfaces
Symbol
Meaning
Symbol
Meaning
Connection to the power supply
PS/2 mouse interface
Protective conductor terminal
PS/2 keyboard-interface
Connection for functional earthing
(equipotential bonding line)
Multimedia Card Reader
DisplayPort interface
Smart Card Reader
DVI-D interface
Line In
LAN interface, not approved for
connecting WAN or telephone
Line Out
Serial port
Microphone input
USB port
Universal Audio Jack
USB 2.0 high-speed port
Headphone output
USB 3.0 super-speed port
USB 3.1 SuperSpeedPlus interface

Siemens SIMATIC IPC RW-543A Specifications

General

Brand	Siemens
Model	SIMATIC IPC RW-543A
Category	Industrial PC
Language	English
