Page #35 background image
Installing and connecting the device
3.2 Mounting the device
SIMATIC IPC RW-543A
Operating Instructions, 03/2023, A5E52332059-AA
35
Horizontal: Mounting on telescopic rails
The device can be installed horizontally in control cabinets and 19" rack systems.
When telescopic rails are used for mounting, the device can be withdrawn fully from the
cabinet or rack. Note the information in "Technical specifications of the telescopic rails
(Page 82)".
Horizontal: Mounting on device base
The device can be installed horizontally in control cabinets and 19" rack systems.
3.2.2 Securing device
WARNING
Dangerous voltage and fire hazard
Improper actions during installation and assembly may lead to personal injury and/or
substantial damage to equipment.
You should observe the installation and assembly notes under:
Notes on mounting (Page 25)
Notes on ambient and environmental conditions (Page 26)
DANGER
Electrocution risk when control cabinet is open
When you open the control cabinet, there may be a dangerous voltage at certain areas or
components.
Touching these areas or components can cause death or serious bodily injury.
Always disconnect the cabinet from the mains before opening it.
Ensure that the power to the control cabinet cannot be turned on accidentally.
