Siemens SIMATIC IPC RW-543A User Manual

BIOS description
11.4 Hardware Monitor menu
SIMATIC IPC RW-543A
Operating Instructions, 03/2023, A5E52332059-AA
105
11.4 Hardware Monitor menu
Hardware Monitor menu
The Hardware Monitor menu displays the system temperature/power status, and allows you
to change the fan settings.
System
parameters
Function description Configuration
options
Default setting
Pc Health Status
CPU
Temperature
The onboard hardware monitor automatically detects and
displays the CPU temperature.
None None
System
temperature
The onboard hardware monitor automatically detects and
displays the system temperature.
None
None
CPU / SYS
Fan Speed
The onboard hardware monitor automatically detects and
displays the CPU / System fan speeds in rotations per minute
(RPM).
None
None
VCC_CPU,
VCC_DDR,
+12V,+5V,
+3.3V
The onboard hardware monitor automatically detects the
voltage output through the onboard voltage regulators.
None
None
CPU_FAN1
Mode
Control the CPU fan.
• [Maximum Mode]: Uses Maximum speed.
• [Automatic Mode]: CPU Fan speed change based on CPU
temperature.
• [Maximum
Mode]
• [Automatic
Mode]
[Automatic Mode]
SYS_FAN1
Mode
Control the system fan1.
• [Maximum Mode]: Uses Maximum speed.
• [Automatic Mode]: CPU Fan speed change based on CPU
temperature.
• [Silent Mode]: A lower sound mode.
• [Maximum
Mode]
• [Automatic
Mode]
• [Silent Mode]
[Automatic Mode]
SYS_FAN2
Mode
Control the system fan2.
• [Maximum Mode]: Uses Maximum speed.
• [Automatic Mode]: CPU Fan speed change based on CPU
temperature.
• [Silent Mode]: A lower sound mode.
• [Maximum
Mode]
• [Automatic
Mode]
• [Silent Mode]
[Automatic Mode]
