Siemens SIMATIC IPC RW-543A User Manual

BIOS description
11.3 Advanced menu
SIMATIC IPC RW-543A
104 Operating Instructions, 03/2023, A5E52332059-AA
System
parameters
Function description Configuration
options
Default setting
Internal
F_USB2_1_1
Enable or disable the Internal F_USB2_1_1.
• [Enabled]
• [Disabled]
[Enabled]
Internal
F_USB2_1_2
Enable or disable the Internal F_USB2_1_2.
• [Enabled]
• [Disabled]
[Enabled]
Internal
F_USB2_2_1
Enable or disable the Internal F_USB2_2_1.
• [Enabled]
• [Disabled]
[Enabled]
Internal
F_USB2_2_2
Enable or disable the Internal F_USB2_2_2.
• [Enabled]
• [Disabled]
[Enabled]
Internal
MiniPCIE
Enable or disable the Internal MiniPCIE.
• [Enabled]
• [Disabled]
[Enabled]
Network Stack Configuration
In the Network Stack Configuration page, you can configure network stack.
System
parameters
Function description Configuration
options
Default setting
Network
Stack
Enable or disable the UEFI Network Stack.
• [Enabled]
• [Disabled]
[Disabled]
The following options show only when "Network Stack = [Enabled]".
Ipv4 PXE
Support
Enable or disable the Ipv4 PXE Boot Support.
• [Enabled]
• [Disabled]
[Disabled]
Ipv6 PXE
Support
Enable or disable the Ipv6 PXE Boot Support.
• [Enabled]
• [Disabled]
[Disabled]
LAN X1P1 Enable or disable the LAN X1P1 Controller.
• [Enabled]
• [Disabled]
[Enabled]
LAN X1P1
PXE BOOT
Enable or disable the LAN X1P1 PXE BOOT.
• [Enabled]
• [Disabled]
[Disabled]
LAN X2P1
Enable or disable the LAN X2P1 Controller.
• [Enabled]
• [Disabled]
[Enabled]
LAN X2P1
PXE BOOT
Enable or disable the LAN X2P1 PXE BOOT.
• [Enabled]
• [Disabled]
[Disabled]
Add-on PCIE
LAN card
PXE Boot
Enable or disable the Add-on PCIE LAN card PXE Boot.
• [Enabled]
• [Disabled]
[Disabled]
