8.4 Electromagnetic compatibility
SIMATIC IPC RW-543A
Operating Instructions, 03/2023, A5E52332059-AA
79
8.4 Electromagnetic compatibility
See the note in "Applicability of technical specifications (Page 75)".
Interference emission
EN 61000-6-4
CAN/CSA CISPR32:17 Class A, EN 55032 Class A; FCC Class A;
EN 61000-3-2 class D, EN 61000-3-3
Emitted interference
Conducted Emission (AC): IEC 61000-6-4 + A1, IEC 61131-2
• 0.15 to 0.5 MHz: 79 dB (μV) QP, 66 dB (μV) A
• 0.5 to 30 MHz: 73 dB (μV) QP, 60 dB (μV) A
Conducted Emission (Telecommunications/network): IEC 61000-6-4 + A1
• 0.15 to 0.5 MHz: 97 dB (μV) - 87 dB (μV) QP, 84 dB(µV) – 74 dB(µV) A
• 0.5 to 30 MHz: 87 dB (μV) QP, 74 dB (μV) A
Radiation Emission: IEC 61000-6-4, CISPR 32:17
1
• 30 to 230 MHz: 40 dB(μV/m) QP (10 m distance)
• 230 to 1000 MHz: 47 dB (μV/m) QP (10 m distance)
• 1 to 3 GHz: 76 dB (μV/m) P; 56 dB (μV/m) A (3 m distance)
• 3 to 6 GHz: 80 dB (μV/m) P; 60 dB (μV/m) A (3 m distance)
Harmonic currents: EN 61000-3-2 class D
Voltage fluctuation and flicker: EN 61000-3-3
Noise immunity on supply lines
± 2 kV; according to IEC 61000-4-4; burst
± 1 kV line-to-line; according to IEC 61000-4-5; surge
± 2 kV line-to-earth; according to IEC 61000-4-5; surge
Noise immunity on signal lines
± 2 kV; according to IEC 61000-4-4; burst; length > 30 m
± 1 kV ; according to IEC 61000-4-4; burst; length < 30 m
± 2 kV shielding-to-earth; according to IEC 61000-4-5; surge; length > 30 m
Immunity to discharges of static
electricity
± 4 kV contact discharge (according to IEC 61000-4-2)
± 8 kV atmospheric discharge; (according to IEC 61000-4-2)
Immunity to RF interference Radiation Immunity (according to IEC 61000-4-3)
• 10 V/m; 80 up to 1000 MHz
80% AM (1 kHz)
• 3 V/m; 1.4 to 2 GHz
80% AM (1 kHz)
• 3 V/m; 2 to 6 GHz
80% AM (1 kHz)
Conducted Immunity (according to IEC 61000-4-6)
• 150 kHz to 80 MHz: 10 V, 80% AM (1 kHz)
Magnetic field
30 A/m; 50 Hz; 60 Hz (according to IEC 61000-4-8)
1
: With a clamp filter(Ferrite Core with Case) on the DVI-D cable near the DVI-D port of the IPC
RW-543A, you need to meet the following requirements:
• The impendence of the clamp filter need to be at least 200 ohm at 100MHz to 1000MHz.
• The aperture of the clamp filter and inner diameter of DVI-D cable should be as close as
possible.
