Siemens SIMATIC IPC RW-543A - Technical Specifications; Applicability of Technical Specifications; General Technical Specifications

SIMATIC IPC RW-543A
Operating Instructions, 03/2023, A5E52332059-AA
75
Technical specifications
8
8.1 Applicability of technical specifications
Note
The following technical specifications only apply under the following conditions:
•
The device is in good working order.
•
The fan cover and filter pad are installed.
•
The device is closed.
•
The connected I/O devices meet the requirements for the respective area of application
(interference emission according to EN 61000-6-4 / IEC 61000-6-4, immunity to
interference according to EN 61000-6-2 / IEC 61000-6-2).
8.2 General technical specifications
See the note in "Applicability of technical specifications (Page 75)".
Article number
6AG4011-3....-...1 (for details, refer to the ordering documentation)
Dimensions
481 × 176 × 509 (W × H × D in mm)
Detailed dimensional specifications can be found in "Dimension drawings (Page 87)".
Weight
13.3 up to 17 kg; depending on the equipment
Power Supply
• Input Rating:
– 350 W: 100 V AC to 240 V AC; 6A to 3A; 47-63Hz
– 500 W: 100 V AC to 240 V AC; 8A to 4A; 47-63Hz
– 850 W: 100 V AC to 240 V AC; 12A to 6A; 47-63Hz
• Rated output power:
– 350 W: (+3.3 V & +5 V≤105 W)
– 500 W: (+3.3 V & +5 V≤105 W)
– 850 W (+3.3 V & +5 V≤200 W)
