Technical specifications
8.9 Technical specifications of the interfaces
SIMATIC IPC RW-543A
82 Operating Instructions, 03/2023, A5E52332059-AA
8.9 Technical specifications of the interfaces
Observe the information in "Applicability of technical specifications (Page 75)" and use only
original connections of the I/O to be connected.
COM
On the rear panel:
• 1 × RS232 (DB9/M)
On the motherboard:
• 3 × RS232 (9-pin header)
• 1 × RS232/RS422/RS485 (9-pin header)
• 1 × RS232/RS485 (9-pin header)
Digital Monitor
Connection of each digital monitor
• 1 × HDMI
• 1 × DVI-D
Analog Monitor
Connection of an analog monitor
• 1 × VGA
Keyboard
Connection through PS/2 or USB port
Mouse
Connection through PS/2 or USB port
USB
On the rear panel:
• 4 × USB 3.2 Gen1
• 2 × USB 2.0
On the front panel:
• 2 × USB 2.0 (500 mA)
On the motherboard:
• 1 × USB 2.0 vertical
• 2 × USB 2.0
Ethernet
2 × Ethernet interface (RJ45, 10/100/1000 Mbps)
Wake on LAN, remote boot supported.
Audio Realtek® ALC662, 5.1 channels, high definition audio codec.
• Micro
• Line In
• Line Out
8.10 Technical specifications of the telescopic rails
Ultimate load per pair
≥ 30 kg
Full extraction length
≥ 470 mm
Rail thickness
≤ 9.7 mm
Mounting screws
M5 x 6 mm
The mounting screws of the telescopic rails may not protrude by more than 5 mm into
the enclosure.
