Expanding and assigning parameters to the device
6.1 Open the device
SIMATIC IPC RW-543A
50 Operating Instructions, 03/2023, A5E52332059-AA
Requirement
• The front door is open; see "Opening the front door (Page 47)".
• The device is fully disconnected from the line voltage, see "Switching off the device
(Page 44)".
• All connection cables are unplugged.
• PH2 screwdriver
Procedure
1. Remove the retaining screws ①.
2. Move the cover in the direction as the arrow.
3. Lift the cover from the back and remove it.
