Alarm, error and system messages
11.2 Error messages and causes for MOBY D with ASM and FC/FB 45 (direct MDS addressing)
MOBY D
System Manual, 01/2010, J31069-D0147-A6-7618
289
Error code
(B#16#..)
Description
0A Another init_run was started without waiting for ready during execution of the
init_run command
 Do
not set init_run cyclically
 The same physical ASM channel is used in two (or more) UDT 10 structures.
Check ASM_address and ASM_channel in all UDT 10 structures.
0B init_run cannot be executed; cyclic Process image for ASM is faulty; FC/FB 45
signals timeout of process image to ASM
This error can be deactivated by writing the value #00 to address DBB 58 in UDT
10. In certain error situations, FC/FB 45 will then, however, not generate an error
message and "seize up".
 ASM_address in UDT 10 is parameterized incorrectly. ASM_address may be for
wrong module.
 ASM_channel setting is ≥16 or ≤0
 ASM hardware/firmware is faulty.
 The same physical ASM channel is used in two (or more) UDT 10 structures.
Check ASM_address and ASM_channel in
all UDT 10 structures.
0C Area length error on block move for FC/FB 45.
 DAT_DB does not exist or is too small. Check DAT_DB_number and
DAT_DB_address in UDT 20
 Execute an init_run
0D An init_run was not completed correctly. The process image is not consistent.
 Run init_run again
 Turn ASM off and on again.
 The RUN/STOP switch on the CPU was pressed rapidly several times in
succession (particularly with slow PROFIBUS DP baud rates)
 The same physical ASM channel is used in two (or more) UDT 10 structures.
Check ASM_address and ASM_channel in
all UDT 10 structures.
