Alarm, error and system messages
11.2 Error messages and causes for MOBY D with ASM and FC/FB 45 (direct MDS addressing)
MOBY D
290 System Manual, 01/2010, J31069-D0147-A6-7618
error_BUS
Table 11- 9 Error variable "error_BUS"
Error code
(W#16#...)
Description
800A ASM is not ready (temporary message).
 This message is given to a user who is not using FC/FB 45 and is polling the
ASMs acyclically, one after the other, very quickly.
8x7F Internal error on parameter x. Cannot be remedied by the user.
8x22
8x23
Area length error on reading parameter.
Area length error on writing parameter.
This error code indicates that parameter x is partially or completely
outside the operand area or the length of a bit array for an ANY parameter is not
divisible by 8.
8x24
8x25
Area error on reading parameter.
Area error on writing parameter.
This error code indicates that parameter x is within an area not allowed for the system
function.
8x26 Parameter contains a time cell number which is too high.
8x27 Parameter contains a counter cell number which is too high.
8x28
8x29
Alignment error on reading parameter.
Alignment error on writing parameter.
The reference to parameter x is an operand whose bit address is not equal to 0.
8x30
8x31
The parameter is located within the write-protected global DB.
The parameter is located within the write-protected instance DB.
8x32
8x34
8x35
The parameter contains a DB number which is too high.
The parameter contains an FC number which is too high.
The parameter contains an FB number which is too high.
8x3A
8x3C
8x3E
The parameter contains a DB number which is not loaded.
The parameter contains an FC number which is not loaded.
The parameter contains an FB number which is not loaded.
8x42
8x43
An access error occurred while the system was attempting to read a parameter from
the I/O area of the inputs.
An access error occurred while the system was attempting to write a parameter to the
I/O area of the outputs.
8x44
8x45
Error on nth (n > 1) read access after an error occurred.
Error on nth (n > 1) write access after an error occurred.
8090 Specified logical base address is invalid: There is no assignment in the SDB1/SDB2x,
or it is not a base address.
8092 A type other than BYTE has been specified in an ANY reference.
8093 The area identifier contained in the configuration (SDB1, SDB2x) of the logical
address is not permitted for these SFCs. The following are permitted:
 0 = S7-400
 1 = S7-300
 2, 7 = DP modules
