Siemens SIMATIC MOBY D User Manual

Alarm, error and system messages
11.2 Error messages and causes for MOBY D with ASM and FC/FB 45 (direct MDS addressing)
MOBY D
System Manual, 01/2010, J31069-D0147-A6-7618
291
Error code
(W#16#...)
Description
80A0 Negative acknowledgment while reading from module. FC/FB fetches
acknowledgment although no acknowledgment is ready.
A user who is not using the FC/FB 45 would like to fetch DS 101 (or DS 102 to 104)
although no acknowledgment is available.
 Perform an init_run for new synchronization between ASM and application.
80A1 Negative acknowledgment while writing to the module. FC/FB sends command
although ASM is unable to receive a command.
80A2 DP protocol error in layer 2. Could be a hardware defect.
80A3 DP protocol error in Direct-Data-Link-Mapper or User-Interface/User. Could be a
hardware defect.
80B0
 SFC not possible for module type
 Data record unknown to module
 Data record number ≥ 241 is not allowed.
 Data records 0 and 1 are not permitted for SFC58 "WR_REC."
80B1 The length specified in the RECORD parameter is wrong.
80B2 The configured slot is not occupied.
80B3 Actual module type is not the module type specified in SDB1.
80C0
 RDREC:
The module has record, but it doesn't have any read data.
 WRREC:
ASM is not ready to receive new data
– Wait until the cyclic counter has been incremented
80C1 The data of the preceding write job on the module for the same data record have not
yet been processed by the module.
80C2 The module is currently processing the maximum possible number of jobs for a CPU.
80C3 Required resources (memory, etc.) are currently in use.
This error is not reported by the FC/FB 45. If this error occurs, the FC/FB 45 waits
until the system is able to provide resources again.
80C4 Communication error
 Parity error
 SW ready not set
 Error in block length management
 Checksum error on CPU side
 Checksum error on module side
80C5 Distributed I/O not available
