4.3 Installation guidelines
MOBY D
44 System Manual, 01/2010, J31069-D0147-A6-7618
SLG D12/D12S
Table 4- 15 Reduction of field data by metal (in %): MDS and SLG D12/D12S
SLG D12/D12S
Transponder
Without metal On metal Flush-mounted
In metal
(50 mm all-
round)
Without metal 100 80 70
On metal; distance 20 mm 70 70 60
MDS D100
Flush-mounted in metal;
distance all-round 20 mm
65 55 55
Without metal 100 80 70
On metal; distance 25 mm 80 65 55
MDS D124
Flush-mounted in metal;
distance all-round 25 mm
65 55 50
Without metal 100 65 65 MDS D139
On metal; distance 30 mm 90 65 65
Without metal 100 80 80 MDS D160
On metal; distance 25 mm 100 80 80
Without metal 100 80 70
On metal; distance 25 mm 80 65 55
MDS D324
Flush-mounted in metal;
distance all-round 25 mm
65 55 50
Without metal 100 80 70
On metal; distance 25 mm 80 65 55
MDS D424
Flush-mounted in metal;
distance all-round 25 mm
65 55 50
Without metal 100 80 80 MDS D428
On metal 80 70 70
Without metal 100 80 80 MDS D460
On metal; distance 25 mm 80 70 70
Without metal 100 80 70
On metal; distance 20 mm 70 70 60
MDS D200
Flush-mounted in metal;
distance all-round 20 mm
65 55 55
