Planning the MOBY D system
4.3 Installation guidelines
MOBY D
System Manual, 01/2010, J31069-D0147-A6-7618
45
SLG D11/D11S with ANT D5
Table 4- 16 Reduction of field data by metal (in %): MDS and SLG D11/D11S with ANT D5
SLG D11/D11S with ANT D5
Transponder
On metal
100 mm distance
Flush-mounted
in metal
100 mm distance
(150 mm all-round)
Without metal 100 95
On metal; distance 20 mm 60 55
MDS D100
Flush-mounted in metal;
distance all-round 20 mm
45 40
Without metal 100 95
On metal, distance 25 mm 60 55
MDS D124
Flush-mounted in metal;
distance all-round 25 mm
40 35
Without metal 100 95 MDS D139
On metal, distance 30 mm 80 75
Without metal 100 90
On metal; distance 25 mm 55 50
MDS D160
1)
Flush-mounted in metal;
distance all-round 25 mm
-- --
Without metal 100 95
On metal; distance 25 mm 60 55
MDS D324
Flush-mounted in metal;
distance all-round 25 mm
40 35
Without metal 100 95
On metal; distance 25 mm 60 55
MDS D424
Flush-mounted in metal;
distance all-round 25 mm
40 35
Without metal 100 95 MDS D428
On metal 40 35
Without metal 100 95 MDS D460
On metal; distance 25 mm 40 35
Without metal 100 95
On metal; distance 20 mm 60 55
MDS D200
Flush-mounted in metal;
distance all-round 20 mm
45 40
1)
Values apply to metal surfaces greater than 100 mm x 100 mm
