Siemens SIMATIC MOBY D User Manual

Planning the MOBY D system
4.3 Installation guidelines
MOBY D
46 System Manual, 01/2010, J31069-D0147-A6-7618
SLG D10/D10S with ANT D5
Table 4- 17 Reduction of field data by metal (in %): MDS and SLG D10/D10S with ANT D5
SLG D10/D10S with ANT D5
Transponder
On metal Flush-mounted in metal
(150 mm all-round)
Without metal 100 95
On metal; distance 20 mm 65 60
MDS D100
Flush-mounted in metal;
distance all-round 20 mm
45 40
Without metal 100 95
On metal; distance 25 mm 85 80
MDS D124
Flush-mounted in metal;
distance all-round 25 mm
65 60
Without metal 100 95 MDS D139
On metal, distance 30 mm 90 85
Without metal 100 95
On metal; distance 25 mm 70 65
MDS D160
1)
Flush-mounted in metal;
distance all-round 25 mm
25 20
Without metal 100 95
On metal; distance 25 mm 75 70
MDS D324
Flush-mounted in metal;
distance all-round 25 mm
-- --
Without metal 100 95
On metal; distance 25 mm 75 70
MDS D424
Flush-mounted in metal;
distance all-round 25 mm
-- --
Without metal 100 95 MDS D428
On metal -- --
Without metal 100 95 MDS D460
On metal; distance 25 mm -- --
Without metal 100 95
On metal; distance 20 mm 65 60
MDS D200
Flush-mounted in metal;
distance all-round 20 mm
-- --
1)
Values apply to metal surfaces greater than 100 mm x 100 mm
