Planning the MOBY D system
4.3 Installation guidelines
MOBY D
System Manual, 01/2010, J31069-D0147-A6-7618
47
SLG D10/D10S with ANT D6
Table 4- 18 Reduction of field data by metal (in %): MDS and SLG D10/D10S with ANT D6
SLG D10/D10S with ANT D6
Transponder
On metal Flush-mounted in metal
(200 mm all-round)
Without metal 100 95
On metal; distance 20 mm 65 60
MDS D100
Flush-mounted in metal;
distance all-round 20 mm
-- --
Without metal 100 95
On metal, distance 25 mm 80 75
MDS D124
Flush-mounted in metal;
distance all-round 25 mm
-- --
Without metal 100 90 MDS D139
On metal, distance 30 mm 80 70
Without metal 100 90
On metal; distance 25 mm 60 55
MDS D160
1)
Flush-mounted in metal;
distance all-round 25 mm
-- --
Without metal 100 95
On metal; distance 25 mm 75 70
MDS D324
Flush-mounted in metal;
distance all-round 25 mm
-- --
Without metal 100 95
On metal; distance 25 mm 75 70
MDS D424
Flush-mounted in metal;
distance all-round 25 mm
-- --
Without metal 100 95 MDS D428
On metal 70 65
Without metal 100 95 MDS D460
On metal 70 65
Without metal 100 95
On metal; distance 20 mm 65 60
MDS D200
Flush-mounted in metal;
distance all-round 20 mm
-- --
1)
Values apply to metal surfaces greater than 100 mm x 100 mm
