Planning the MOBY D system
4.3 Installation guidelines
MOBY D
System Manual, 01/2010, J31069-D0147-A6-7618
57
NOTICE
It must be noted that the overall sensing range of the antennas is greater than the sensing
range to be configured. This means there can be label alignments where even labels
outside the sensing range will be detected. Labels aligned in parallel with the antennas, for
example, can also be detected at larger distances beside or outside the antenna range.
For this reason, goods with labels must not be stored within a distance of up to 0.5 m from
the installation. If this cannot be complied with, the antennas must be shielded.
To achieve three-dimensional detection of the labels in the sensing range, the following
requirements must be met:
The gate width must be less than or equal to 800 mm.
The antenna size of the labels must be at least the size of an ISO card (85 mm x 54
mm).
The distance from label to label must be greater than 100 mm. The distance from label
to label can be reduced if the gate width is correspondingly reduced. This applies
especially for distances under 50 mm
There must be no more than 16 labels within the sensing range of the antennas at the
same time.
The number of labels can be increased if the gate width is correspondingly reduced and
the maximum speed appropriately adapted.
The maximum speed of the labels must not exceed 1 m/s. (This depends on the number
and alignment of the labels, the number of data blocks to be processed, the data
protocol required and the label type).
To the front and sides of the antenna, there must be a distance of more than 150 mm to
metal parts.
There must be no interference to the write/read device from other electrical equipment in
the surrounding area.
Note
The SLG D10S is not multitag-enabled.
Components required
For installation with
● 2 antennas (gate)
● 3 antennas (C arrangement)
● 4 antennas (tunnel)
the following components are required:
