Planning the MOBY D system
4.3 Installation guidelines
MOBY D
58 System Manual, 01/2010, J31069-D0147-A6-7618
Number for installation
with
2 ant. 3 ant. 4 ant.
Component Order No.
1 1 1 Basic unit:
SLG D10 (↔ PC)
SLG D10S ↔ ASM 4xx/RF1xx)
SLG D10S: 6GT2698-1AA00
SLG D10S: 6GT2698-2AA00
optionally:
ASM 452: 6GT2002-0EB20
ASM 473: 6GT2002-0HA10
ASM 475: 6GT2002-0GA10
ASM 456: 6GT2002-0ED00
RF170C: 6GT2002-0HD00/
6GT2002-1HD00
RF180C: 6GT2002-0JD00
RF182C: 6GT2002-0JD10
2 3 4 Antenna ANT D5 / D6 / D10 optionally:
ANT D5: 6GT2698-5AA00
ANT D6: 6GT2698-5AB00
ANT D10: 6GT2698-5AF00
2 3 4 With ANT D5 if required:
spacer kit for ANT D5 6GT2690-0AB00
2 3 4 With ANT D6 if required:
cover 6GT2698-5AD00
1 2 3 Antenna duplexer 6GT2603-0AC00
1 1 1 MOBY wide-range power supply unit
for SIMATIC RF systems
EU: 6GT2898-0AA00
UK: 6GT2898-0AA10
US: 6GT2898-0AA20
1 1 1 24 V connecting cable,
5 m in length
6GT2491-1HH50
1 1 1 Connecting cable:
SLG D10 ↔ PC
or
SLG D10S ↔ ASM 4xx/RF1xx
6GT2691-0B …
optionally:
6GT2491-0E …
6GT2491-1C …
6GT2691-0F …
6GT2691-0FH20
Installation information
The cables on the antennas and the antenna duplexer are 3.3 m or 10.5 m long respectively.
The write/read device must be installed in the vicinity of the antennas. In the case of larger
distances between the write/read device and the antennas, the antenna cable can be
increased by 7.2 m with the extension (6GT2 691-0DH72). This results in shorter ranges.
