Display
13.1 CPU display
S7-1500R/H redundant system
System Manual, 01/2024, A5E41814787-AF
437
Regarding ②: Names of the menus
The following table shows the available menus of the display.
Table 13- 2 Names of the menus
The "Overview" menu contains information about:
• Properties of the local CPU
• Properties of the F-CPU
– Status of the safety mode
– Collective signature
– Date of the last changes
• Redundancy properties, for example
– Display of role (primary CPU or backup CPU)
– Displaying and setting the redundancy ID
– Display of the pairing state
• Properties of the inserted SIMATIC memory card
Diagnostics The "Diagnostics" menu includes:
• Display of alarms
• Display of the diagnostics buffer
• Read and write access to force and watch tables
• Display of cycle time
• Display of memory used
In the "Settings" menu you:
• Assign IP address and PROFINET device name of the CPU
• Setting date/time
• Set operating states (RUN/STOP)
• Perform a CPU memory reset or reset to factory settings
• Disabling and enabling passwords
• Disable/enable display with display password
• Format SIMATIC memory card
• Run firmware update and display status
• Convert SIMATIC memory card or delete user program
The "Modules" menu is not supported for R/H-CPUs.
In the "Display" menu you can configure settings related to the display, such
as language setting, brightness and energy-saving mode. The energy-saving
mode dims the display. Standby mode switches off the display.
