Display
13.1 CPU display
S7-1500R/H redundant system
438 System Manual, 01/2024, A5E41814787-AF
Menu icons
The following table shows the icons that are displayed in the menus.
Table 13- 3 Menu icons
Select the required language.
A message is available in the next lower level page.
There is an error in the next lower level page.
The marked module is not accessible.
Navigate to the next lower level page.
In edit mode you make the selection using two arrow keys:
• Down/up: Jumps to the selection or is used to select the desired digits/options.
In edit mode you make the selection using four arrow keys:
• Down/up: Jumps to the selection or is used to select the desired digits.
• Left/right: Jumps one place forward or back.
The alarm is not yet acknowledged.
The alarm is acknowledged.
