● at current outputs
– inductive load
max. 500 Ω
600 Ω at reduced U
CM
to < 1 V
max. 1 mH
Voltage output
● Short-circuit protection
Yes
● Short-circuit-current
Maximum 30 mA
current output
● No-load voltage
max. 19 V
Destruction limit against externally applied voltages / currents
● Voltage at the outputs against MANA
max. 20 V continuous
75 V for1 ms (duty cycle 1:20
● Current
max. 40 mA continuous
Connection of actuators
● for voltage output
– 2-wire connection
– 4-wire connection (measurement cable)
possible, without compensation of line resis‐
tances
Possible
● for current output
– 2-wire connection
Possible
Analog modules
5.26 Analog output module SM 432; AO 8 x 13 Bit (6ES7432-1HF00-0AB0)
S7-400 Automation System Module Data
Reference Manual, Ausgabe 11/2016, A5E00850736-08 321
