● for capacitive load
3.5 ms
● for inductive load
0.5 ms
Noise suppression, error limits
Noise suppression for f = n (f1 ± 1%), (f1 = interfering frequency) n= 1.2 ...
● Common mode interference (UCM < AC 3 Vss / 50
Hz)
> 60 dB
Crosstalk between the outputs > 40 dB
Operational limit (in the entire temperature range, relative to output range)
● Voltage output
– ± 10 V
– 0 to 10 V
– 1 to 5 V
± 0.5%
± 0.5%
± 0.5%
● current output
– ± 20 mA
– 4 to 20 mV
± 1%
± 1%
Basic error limit (operational limit at 25°C, relative to output range)
● Voltage output
– ± 10 V
– 0 to 10 V
– 1 to 5 V
± 0.5%
± 0.5%
± 0.5%
● current output
– ± 20 mA
– 0 to 20 mA
± 0.5%
± 0.5%
Temperature error (relative to output range) ± 0.02 % / K
Linearity error (relative to output range) ± 0.05%
Repeat accuracy (in settled state at 25 °C, relating to
output range)
± 0.05%
Output ripple; bandwidth 0 to 50 kHz (relative to output
range)
± 0.05%
Status, interrupts, diagnostics
Interrupts None
Diagnostic functions None
Substitute values can be connected No
Data for selecting an actuator
Output range (nominal values)
● Voltage
± 10 V0 to 10 V1 to 5 V
● Current
± 20 mA
0 to 20 mA
4 to 20 mA
Load impedance (in rated range of output)
● at voltage outputs
– capacitive load
min. 1 kΩ
max. 1 µF
Analog modules
5.26 Analog output module SM 432; AO 8 x 13 Bit (6ES7432-1HF00-0AB0)
S7-400 Automation System Module Data
320 Reference Manual, Ausgabe 11/2016, A5E00850736-08
