Bytes 4 to 8 of the SM 422; DO 16 x AC 20-120 V/2 A
Table B-16 Bytes 4 to 8 of the diagnostic data of the SM 422; DO 16 x AC 20-120 V/2 A
Byte Bit Meaning
Byte 4 7 0
6 Channel type B#16#72: digital output
5
4
3
2
1
0
Byte 5 7 Number of diagnostics bits that the module outputs per channel: 8 bits long
0
Byte 6 7 Number of channels of the same type in one module: 16 channels
0
Byte 7 7 Channel error 7
6 Channel error 6
5 ...
4 ...
3 ...
2 ...
1 Channel error 1
0 Channel error 0
Diagnostic data of signal modules
B.4 Diagnostic data of the digital output modules as of byte 2
