Byte Bit Meaning
Byte 8 7 Channel error 15
6 Channel error 14
5 ...
4 ...
3 ...
2 ...
1 Channel error 9
0 Channel error 8
Bytes 9 to 24 of the SM 422; DO 16 x AC 20-120 V/2 A
Data record 1 contains the channel-specific diagnostic data, starting at bytes 9 to 24. The figure
below shows the assignment of the diagnostic byte for a channel of the module.
Table B-17 Diagnostic byte for a channel of the SM 422; DO 16 x AC 20-120 V/2 A
Byte Bit Meaning
Bytes 9 - 24 7 0
6 0
5 Fuse blown
4 0
3 0
2 0
1 0
0 Configuring/parameter assignment error
Diagnostic data of signal modules
B.4 Diagnostic data of the digital output modules as of byte 2
