Siemens SIMATIC TeleControl DNP3 User Manual

Configuration - DNP3
Configuration Manual, 11/2018, C79000-G8976-C508-01
11
Functions and requirements
1
1.1
Communications modules
Communications modules for the telecontrol protocol DNP3
The following SIMATIC NET communications modules can be used for the telecontrol
protocol DNP3.
You will find the TIM 4R-IE DNP3 with article number 6NH7803-4BA00-0AA0 twice in the
STEP 7 catalog, as built-in unit (S7-300 rack) and as stand-alone device.
Meaning of symbols in the table:
● X = Supported
● - = Not supported
Table 1- 1 Communications modules for DNP3
Module
Article number
Number of inter-
faces *
Station type
STEP 7
product
Required
firmware
IE
RS
Master
Node station
Station
TIM 1531 IRC
6GK7 543-1MX00-0XE0
3 1 X X X STEP 7
Professional
V2.0
TIM 4R-IE DNP3 /
TIM 4R-IE DNP3 Stand-alone
6NH7803-4BA00-0AA0
2 2 X X X STEP 7
Professional
V3.2
TIM 3V-IE DNP3
6NH7803-3BA00-0AA0
1 1 X X X STEP 7
Professional
V3.2
CP 1243-8 IRC
6GK7 243-8RX30-0XE0
1
- ***
-
-
X STEP 7
Basic
**
/
Professional
V3.1
CP 1243-1
6GK7 243-1BX30-0XE0
6AG1 243-1BX30-2AX0
1
-
-
-
X STEP 7
Basic
**
/
Professional
V3.1
CP 1542SP-1 IRC
6GK7 542-6VX00-0XE0
1
-
-
-
X STEP 7
Professional
V2.0
*
IE = Ethernet interfaces, RS = serial interfaces
**
STEP 7 Basic with connection of the CP to a third-party master. See note below.
*** The connection of a TS-Module to the CP 1243-8 IRC is not supported for DNP3.
