Diagnostics
4.4 SNMP
Configuration - DNP3
136 Configuration Manual, 11/2018, C79000-G8976-C508-01
5. In the "Connect online" dialog, go to the Choose the entry "TeleService via telecontrol" in
the "Type of PG/PC interface" drop-down list.
6. In the "PG/PC interface" drop-down list select the entry "TeleService board".
7. In the table select the TIM if it is not already selected.
The path both via the TIM or also via the CPU is possible.
8. Click on the
icon next to the "PG/PC interface" drop-down list.
The "Establish remote connection via telecontrol" dialog box opens.
9. Make the necessary entries in this dialog (see below) and click on "Connect".
Terminate online connection
On completion of the online session, terminate the online connection again using the
"Disconnect" button.
SNMP
SNMP (Simple Network Management Protocol)
SNMP is a protocol for management and diagnostics of networks and nodes in the network.
To transmit data, SNMP uses the connectionless UDP protocol.
The information on the properties of SNMP-compliant devices is entered in MIB files (MIB =
Management Information Base).
Scope of performance of the module as SNMP agent
Not all functions described below are available with every module. Refer to the manual of the
respective module for information on the functional scope.
The communication modules support data queries in the following SNMP versions:
● SNMPv1 (standard)
● SNMPv3 (Security)
They return the contents of MIB objects of the standard MIB II according to RFC1213 and
the Siemens Automation MIB.
●
The MIB supports the following groups of MIB objects:
– System
– Interfaces
The "Interfaces" MIB object provides status information about the module interfaces.
– IP
– ICMP
