Siemens SIMATIC TeleControl DNP3 User Manual

Functions and requirements
1.5 Performance data and configuration limits
Configuration - DNP3
18 Configuration Manual, 11/2018, C79000-G8976-C508-01
●
TIM 3V-IE DNP3
Number in total: Max. 8,
of which:
– Via the Ethernet interface: Max. 8
– Via the RS-232 interface: Max. 8
Note
Double the connection resources with direct communication between stations (only via
Ethernet or dial-up network)
Note that when there is direct communication between two stations, 2 connection
resources
are occupied per station: One for the master station connection, one for the station
connection.
Table 1- 2 Overview of the connection resources
TIM type
Subscriber type /
interface configura-
tion
Max. number of
connections per
TIM in total
Interface
Network type
Max. number of
connections per
interface
TIM 4R-IE DNP3 Master station 128
*
Ethernet 1
TCP
64
Ethernet 2
TCP
64
RS232 no. 1
Dedicated line
32
Dialup network
32
RS232 no. 2
Dedicated line
32
Dialup network
32
Station 32
Ethernet 1
TCP
16
Ethernet 2
TCP
16
RS232 no. 1
Dedicated line
16
Dialup network
16
RS232 no. 2
Dedicated line
16
Dialup network
16
TIM 3V-IE DNP3 Master station /
node station
8
Ethernet
TCP
8
RS232 Dedicated line 8
Dialup network
8
Station 8 Ethernet TCP 8
RS232
Dedicated line
8
Dialup network
8
*
The total number of 128 also applies to the TIM 4R IE DNP3 as a node station. The maximum number per interface is
obtained from the information in the "Master station" or "Station" rows.
Number of communications objects per TIM
The maximum number of communications objects for DNP3 communication per TIM is 100.
