TIM DNP3
System Manual, 12/2015, C79000-G8976-C253-04
139
The SINAUT Configuration Tool
Installing / uninstalling
6.1.1
Installation of the SINAUT standard software package
To install individual or all components of the engineering software, the required versions of
the following components must exist on the PC:
● Windows operating system
● STEP 7
You will find the required versions of these software components in Preface (Page 3).
If the Autorun feature is activated on your PC/PG, the SINAUT setup program starts
automatically when you insert the CD. Otherwise, use the Explorer to open the root directory
on the CD and click on the Setup.exe application.
The setup program checks which components on the CD can be installed and then displays
a list from which you can make your selection. Setups are currently available for the
following components.
● SINAUT configuration tool: Basic version
● SINAUT TD7 Library
Select the components you want to install (you can select several packages at once using
shift-click) and start the installation by clicking the Install button. To configure DNP3 systems,
the TD7 Library component does not necessarily need to be installed.
During installation, the setup program will prompt you for or display any further information
necessary.
The installation programs perform the following individual operations:
● The programs and data supplied with the engineering software are copied to the correct
locations in the STEP 7 directory.
● A new submenu SINAUT ST7 containing the tools of the engineering software is
integrated in the SIMATIC menu in the Windows Start menu.
● A SINAUT ST7 Configuration icon is created on your desktop.
Note
The engineering software registers in the Microsoft Windows system files. Do not use
Microsoft Windows tools such as the Explorer to move or rename SINAUT
files or folders or
7 data in the Microsoft Windows registry. Following such modifications, your
program may no longer functioning correctly.
