Siemens SIMATIC TIM 3V-IE DNP3 User Manual

Technical specifications
8.2 Technical specifications of the TIM 4R-IE DNP3
TIM DNP3
System Manual, 12/2015, C79000-G8976-C253-04
301
Technical specifications of the TIM 3V-IE DNP3
Transmission protocol Ethernet
Protocol
DNP3
Transport protocol
• TCP
• UDP
Communication services
• DNP3 using S7 communication
• PG communication
* You will find further product characteristics in the section Uses and properties of the TIM
(Page 13).
8.2
Technical specifications of the TIM 4R-IE DNP3
Table 8- 2 Technical specifications of the TIM 4R-IE DNP3
Technical specifications of the TIM 4R-IE DNP3
Article number
6NH7803-4BA00-0AA0
Connection to WAN classic
Number
2
Execution
Serial port, 9-pin D-sub male connector
Standard (can be changed in the
configuration)
• RS-232
• RS-485
Maximum permitted cable length
• RS-232
• RS-485
• 6 m
• 30 m
Transmission speed
9 600 ... 115 200 bps
Connection to LAN or IP-based WAN (Industrial Ethernet)
Number
2
Execution
RJ-45 jack
Properties 10/100BASE-T, IEEE 802, half duplex/full duplex, autocrossover, autonegotiation,
autosensing
Maximum permitted cable length
10 m
Permitted cable lengths (Ethernet) - (Alternative combinations per length range) *
0 ... 55 m
• Max. 55 m IE TP Torsion Cable with IE FC RJ45 Plug 180
• Max. 45 m IE TP Torsion Cable with IE FC RJ45 + 10 m TP Cord via
IE FC RJ45 Outlet
0 ... 85 m
• Max. 85 m IE FC TP Marine/Trailing/Flexible/FRNC/Festoon/Food Cable with
IE FC RJ45 Plug 180
• Max. 75 m IE FC TP Marine/Trailing/Flexible/FRNC/Festoon/Food Cable +
10 m TP Cord via IE FC RJ45 Outlet
0 ... 100 m
• Max. 100 m IE FC TP Standard Cable with IE FC RJ45 Plug 180
• Max. 90 m IE FC TP Standard Cable + 10 m TP Cord via IE FC RJ45 Outlet

Siemens SIMATIC TIM 3V-IE DNP3 Specifications

General

Brand	Siemens
Model	SIMATIC TIM 3V-IE DNP3
Category	Control Unit
Language	English
