Technical specifications
8.2 Technical specifications of the TIM 4R-IE DNP3
TIM DNP3
302 System Manual, 12/2015, C79000-G8976-C253-04
Technical specifications of the TIM 4R-IE DNP3
Exchangeable media
Slot for exchangeable media
C-PLUG (optional)
Electrical data
External power supply
Supply voltage
24 VDC
Permitted range
min. 20.4 V, max. 28.8 V
Execution
2-pin plug-in terminal strip
Current consumption
From 24 VDC, typical
150 mA
From 24 VDC, maximum
170 mA
From backplane bus, maximum
200 mA
Power loss at 24 VDC
Typical
4.6 W
Backup battery (optional)
Backup of:
• Message memory
• Hardware clock
Order number
6ES7 971-0BA00
Battery type
Lithium battery type Tadiran SL-306, cell type AA
Capacitance
2.3 Ah
Voltage (nominal)
3.6 V
Current consumption during backup
typically 100 μA, max. 160 μA
Leakage current
typically 15 μA
Clock
• Hardware clock (real-time clock)
• Backup
• Deviation per day
• yes
• yes, with backup battery (optional)
• max. 4 s
Permitted ambient conditions
Ambient temperature During operation with the rack in-
stalled horizontally
0 ℃ to +60 ℃
During operation with the rack in-
stalled vertically
0 ℃ to +40 ℃
During storage
-40 ℃ to +70 ℃
During transportation
-40 ℃ to +70 ℃
Relative humidity During operation ≤ 95 % at 25 °C, no condensation
Operating altitude During operation ≤ 2,000 m above sea level at max. 60 °C
ambient temperature
Contaminant concentration
Acc. to ISA-S71.04 severity level G1, G2, G3
Design, dimensions and weight
Module format
Compact module for S7-300, double width
Degree of protection
IP20
Weight
400 g
Dimensions (W x H x D)
80 x 125 x 120 mm
