Technical specifications
8.2 Technical specifications of the TIM 4R-IE DNP3
TIM DNP3
System Manual, 12/2015, C79000-G8976-C253-04
303
Technical specifications of the TIM 4R-IE DNP3
Installation options
Installation on a DIN rail
Installation on an S7-300 standard rail
Wall mounting
Mounting in a 19" rack
Switch panel
Product functions *
Configuration
Software for PG
SINAUT configuration software for PG
Storage of TIM configuration data
on internal TIM flash memory
on TIM in optional C-PLUG
on MMC of the S7-300-CPU (if TIM
fitted in S7-300)
TIM can be operated in the role
Station
Node station
Master station
yes
yes
yes
No. of TIM 3V-IE DNP3 modules per
S7-300
1
Local communication Via Ethernet interface
With CPUs, PCs and further TIMs
Possible using S7 communication (for
PCS 7 and TIMs)
Via backplane bus
With local CPU
With further local TIMs
Possible using TD7onTIM
Not possible
When used in an S7-300 controller
Via backplane bus with the S7-300
CPU
Possible using TD7onTIM
Via backplane bus with other TIMs in
the rack
Possible
Via MPI interface of the S7-300 CPU
with other CPUs, TIMs, and/or PCs
Possible using S7 communication (for PCS
7 and TIMs)
Work memory required on the S7
CPU
TD7onTIM software Best case, 0 bytes
Data memory on the TIM
Battery backed
yes
Transmission protocols RS-232/RS-
485
Selectable protocols
DNP3
Asynchronous character format
(DNP3)
10 bits
Hamming distance d (DNP3)
2
Transmission protocol Ethernet
Protocol
DNP3
Transport protocol
TCP
UDP
Communication services
DNP3 using S7 communication
PG communication
