Diagnostics and upkeep
7.3 SINAUT diagnostics and service tool
TIM DNP3
System Manual, 12/2015, C79000-G8976-C253-04
293
The following table contains a summary of all error messages that caused the group error
LED (SF) to light up.
Table 7- 5 Classification of the messages and activation of the group error LED
Error class
Detailed event (hex) in the diagnostics message
Internal error 0061
0063, 0064, 0065, 0066, 0067
0069
0078, 0079, 0080
0083
06B0
External error
0320
No parameter assignment 0070
0071
0620
Bad parameter assignment 0077
0081
0110
0112
0300
031C
0500
0620
RAM error 0085
0086
7.3.6.3
DNP3-specific diagnostics messages of the TIM
Diagnostic messages
Below you will find a list of the DNP3-specific diagnostics messages sorted according to the
detailed event:
Event ID
(hex)
Detailed
event
(hex)
Status message
Meaning
F560 0400 No TD7onTIM configuration exists TD7onTIM configuration data was not transferred to the
module.
F560
0401
Memory error
The available RAM memory on the module is exhausted.
F560
0402
Error receiving message
Internal error
F560 0403 Amount of diagnostics data to high
(> 32 767). Diagnostics data of the
event buffer cannot be transferred
Diagnostics data relating to message management could
not be transferred to the diagnostics tool.
F560
0404
Unknown ORG PDU received
Internal error
