Diagnostics and upkeep
7.3 SINAUT diagnostics and service tool
TIM DNP3
294 System Manual, 12/2015, C79000-G8976-C253-04
Event ID
(hex)
Detailed
event
(hex)
Status message
Meaning
F560
0405
DNP3 data output locked
No DNP3 communication possible
F360 0405 DNP3 data output released DNP3 communication possible
F560
0406
Unknown control message
Internal error
F560
0407
Error releasing memory
The available RAM memory on the module is exhausted.
F560 0408 Time-of-day function not available Time-of-day synchronization by DNP3 master station not
possible
F560
0409
WAN SDB cannot be interpreted
Inconsistent system data block
F560
040A
Error creating a task
Internal error
F560
040B
WAN driver successfully installed.
DNP3 driver loaded
F960
040C
Modem does not set CTS signal
CTS control signal on the serial interface inactive
F860
040C
Modem sets CTS signal again
CTS control signal on the serial interface active
F560 040D WAN interface disrupted Serial communication disrupted. Bad data frame, for
example due to incorrect baud rate or invalid parity.
F460
040D
WAN interface OK
Serial communication is OK again.
F560
040E
WAN driver ready for communication
WAN driver ready
F560
040F
Time synchronization received
DNP3 master station has synchronized system time.
F560 0410
Unsolicited event transmission activated
or deactivated
Request to activate of deactivate unsolicited messages
F560
0411
IP connection established
Connection to DNP3 master station was established.
F360
0411
IP connection terminated
Connection to DNP3 master station was terminated.
F560
0412
Inconsistent routing table
Inconsistent configuration
F360
0413
DNP3 connection disrupted
Connection to specified master station disrupted
F260
0413
DNP3 connection established
Connection to specified master station established
F560 0414 Size of the process image of the inputs Highest DNP3 indexes of the input values (received from
DNP3 master station) are output.
F560 0415 Size of the process image of the out-
puts
Highest DNP3 indexes of the output values (sent to
DNP3 master station) are output.
F560
0416
TD7 data cannot be interpreted
Internal error
F560 0417 Unknown DNP3 subscriber address
received
DNP3 master station sends unknown address. The re-
ceived master station and station address are displayed.
F560 0418 Command rejected A command of the DNP3 master station could not be
executed. Object group, variation and type of the com-
mand are displayed.
F560 0419 Command not supported An unknown or unsupported command of the DNP3
master station was received. Object group, variation and
type of the command are displayed.
F560 0420 Installation abort - DNP3 stack has
detected an inconsistent parameter
assignment.
Configuration error
