Uses and properties of the TIM
1.6 Other properties of the TIM
TIM DNP3
System Manual, 12/2015, C79000-G8976-C253-04
23
Detailed information on DNP3 attributes in the DNP3 device profile
You will find a detailed overview of the attributes and properties specified in the DNP3
protocol and supported by the two DNP3 TIM modules in the DNP3 device profile.
You will find the DNP3 device profiles on the Internet pages of Siemens Automation
Customer Support under the following entry IDs:
●
TIM 3V-IE DNP3
Link: (https://support.industry.siemens.com/cs/ww/en/view/103655295)
●
TIM 4R-IE DNP3
Link: (https://support.industry.siemens.com/cs/ww/en/view/103655863)
1.6
Other properties of the TIM
Compatible SIMATIC families
The following table shows the SIMATIC families in which the two TIM variants can be used.
Can be used in SIMATIC family:
S7-300
S7-400
TIM 3V-IE DNP3
•
no
TIM 4R-IE DNP3
•
•
Interfaces
The table below shows the number of interfaces of the two TIM variants.
Ethernet RJ-45 port
Serial interface for an exter-
nal modem or for connecting
MODBUS slaves
TIM 3V-IE DNP3 1 1
(RS232)
TIM 4R-IE DNP3 2 2
(RS232/RS485)
