Siemens SIMATIC TIM 3V-IE DNP3 User Manual

The SINAUT Configuration Tool
6.8 Changing the configuration
TIM DNP3
System Manual, 12/2015, C79000-G8976-C253-04
237
6.8
Changing the configuration
Changing the configuration
This section describes the required follow-up actions after typical operator activities in the
SINAUT configuration software.
Table 6- 11 Change matrix
Object affected
Action in the SINAUT configu-
ration tool
Necessary follow-up action
Station
Adding a station
-
Station Renaming a station -
Station Changing the parameter set-
tings of a station
-
Station Deleting a station All telecontrol connections running via a module in this station
are then invalid and are removed the next time you open the
connection configuration. When necessary, these must be re-
placed by alternative connections. The SDBs or DBs of all mod-
ules that were involved in these deleted connections must be
regenerated in the subscriber administration.
TIM module
Adding a TIM module
-
TIM module
Renaming a TIM module
-
TIM module Changing the parameter set-
tings of a TIM module
If the parameter settings of a TIM module are changed, the
SDBs only need to be regenerated in the subscriber administra-
tion for this TIM.
Exception:
If parameters are changed in the "WAN Access" tab, this has
effects on all telecontrol connections running via the modified
WAN driver.
TIM module Deleting a TIM module All telecontrol connections running via this module are then
invalid and are removed the next time you open the connection
configuration. When necessary, these must be replaced by
alternative connections. The SDBs or DBs of all modules that
were involved in these deleted connections must be regenerat-
ed in the subscriber administration.
Network
Adding a network
-
Network
Renaming a network
-
Network Changing the parameter set-
tings of a network
The SDBs of all the modules connected to this network must be
regenerated in the subscriber administration. In WAN networks,
these are only TIM modules, in LANs all connected modules.
Network Deleting a network All telecontrol connections running via this network are then
invalid and are removed the next time you open the connection
configuration. When necessary, these must be replaced by
alternative connections. The SDBs or DBs of all modules that
were involved in these deleted connections must be regenerat-
ed in the subscriber administration.
Network nodes
Adding a network node
-
Network nodes
Renaming a network node
-
