Diagnostics and upkeep
7.3 SINAUT diagnostics and service tool
TIM DNP3
System Manual, 12/2015, C79000-G8976-C253-04
247
7.3.1.3
Functions of the SINAUT diagnostics and service tool
Overview of the diagnostic and service functions
The diagnostic functions of the SINAUT diagnostics and service tool can be grouped
together as follows:
● STEP 7 diagnostics
● SINAUT diagnostics (TIM status information and TD7 software diagnostics)
● Message protocol diagnostics
● Service functions
The following table shows the diagnostic and service functions and all the menus in which
the functions of the SINAUT diagnostics and service tool can be called.
The two right-hand columns in the table indicate that the scope of information when using
the
SINAUT subscriber list of a STEP 7 project is greater than when using accessible nodes .
Table 7- 1 Overview of the diagnostic and service functions of the SINAUT diagnostics and service
tool
Function group,
diagnostic function
(remarks)
Subscriber type
relevant for diag-
nostics
Called in
menu
Access over
STEP 7
project
Access us-
ing Accessi-
ble Nodes
STEP 7 diagnostics
STEP 7
diagnostics
CPU messages CPU, TIM " X X
Module information (including mes-
sages in diagnostic buffer)
CPU, TIM " X X
Operating mode
CPU, TIM
"
X
X
Setting the time
CPU, TIM
"
X
X
SINAUT
SINAUT diagnostics
SINAUT
TIM Diagnostics
TIM
"
X
X
TIM subscriber diagnostics
TIM
"
X
X
TIM diagnostic messages
TIM
"
X
TIM Message Monitor
TIM
"
X
TD7 software diagnostics
SINAUT
TD7 CPU diagnostics (TD7 messag-
es in diagnostics buffer)
CPU " X X
TD7 block structure
(configured data)
CPU " X
TD7 block structure for all CPUs
(configured data)
CPU " X
TD7 CPU program comparison
(configured data)
CPU " X
