The SINAUT Configuration Tool
6.6 TD7onTIM
TIM DNP3
System Manual, 12/2015, C79000-G8976-C253-04
163
For some TD7onTIM objects, the communications partner must support certain DNP3
implementation levels. If there are special requirements, you will find the corresponding
information in the right-hand column.
Table 6- 4 Assignment of DNP3 object groups and TD7onTIM objects
Object
group
Variation
Format according
to the DNP3 speci-
fication
Station type
TD7onTIM object
S7 data
type
DNP3 level of the part-
ner ***
1 2 Binary input with
flag
Station
Bin04B_S, Cmd01B_S
BOOL
Master sta-
tion
Bin04B_R
2 2 Binary input event
- with absolute
time
Station
Bin04B_S
BOOL
Cmd01B_S BYTE
Master sta-
tion
Bin04B_R BOOL
10 2 Binary output -
status with flags
Station
Bin08X_S **
BOOL
Cmd01B_R
BYTE
Master sta-
tion
Bin08X_R **
BOOL
Cmd01B_R
BYTE
11 2 Binary output
event - with time
Station
Bin08X_S **
BOOL
As of DNP3 level 4
Master sta-
tion
Bin08X_R
**
12 1 Binary command -
control relay output
block
Station
Bin04B_R
BYTE
Bin08X_R
BOOL
Cmd01B_R
BYTE
DNP3_Cmd01X_R
BOOL
Master sta-
tion
Bin04B_S
BYTE
Bin08X_S ****
BOOL
Cmd01B_S ****
BYTE
20 2 Counter - 16-bit
with flag
Station
Cnt01D_S, Cnt04D_S
WORD
Master sta-
tion
Cnt01D_R, Cnt04D_R
21
*
2 Frozen counter -
16-bit with flag
Station Cnt01D_S, Cnt04D_S WORD DNP3 level 1 to 4
6 Frozen counter -
16-bit with flag and
time
Cnt01D_S, Cnt04D_S WORD DNP3 level 5 only
22 2 Counter event -
16-bit with flag
Station
Cnt01D_S, Cnt04D_S
WORD DNP3 level 1 to 4
Master sta-
tion
Cnt01D_R, Cnt04D_R
6 Counter event -
16-bit with flag and
time
Station
Cnt01D_S, Cnt04D_S
WORD DNP3 level 5 only
Master sta-
tion
Cnt01D_R, Cnt04D_R
