The SINAUT Configuration Tool
6.6 TD7onTIM
TIM DNP3
System Manual, 12/2015, C79000-G8976-C253-04
165
Object
group
Variation
Format according
to the DNP3 speci-
fication
Station type
TD7onTIM object
S7 data
type
DNP3 level of the part-
ner ***
40 *, **
1
Analog output
status - 32-bit with
flag
Station
Dat12D_R
DINT
Par12D_R **
As of DNP3 level 4
Master sta-
tion
Par12D_S **
As of DNP3 level 4
2
Analog output
status - 16-bit with
flag
Station
Ana04W_R,
Mean04W_R
WORD
Set01W_R **
As of DNP3 level 4
Dat12D_R
BYTE, INT,
WORD
Master sta-
tion
Set01W_S **
WORD
As of DNP3 level 4
3
Analog output -
32-bit float with
flag
Station
Dat12D_R
REAL
DNP3 level 5 only
41
1
Analog output -
32-bit
Station
Dat12D_R, Par12D_R
DINT
Master sta-
tion
Dat12D_S
Par12D_S ****
DINT
2
Analog output -
16-bit
Station
Ana04W_R,
Mean04W_R,
Set01W_R
WORD
Dat12D_R
BYTE, INT,
WORD
Master sta-
tion
Ana04W_S,
Mean04W_S;
Set01W_S
****
WORD
Dat12D_S
BYTE, INT,
WORD
3
Analog output -
32-bit float
Station
Dat12D_R
REAL
DNP3 level 5 only
Master sta-
tion
Dat12D_S
42 *, **
3
Analog output
event - 32-bit with
time
Station
Par12D_R **
DINT
As of DNP3 level 4
Master sta-
tion
Par12D_S **
4
Analog output
event - 16-bit with
time
Station
Set01W_R **
WORD
Master sta-
tion
Set01W_S **
110
1 ... 255
Octet string
Station /
master sta-
tion
Dat12D_R, Dat12D_S
CHAR
111
1 ... 255
Octet string event
Station
Dat12D_S
CHAR
Master sta-
tion
Dat12D_R
*
The object groups 21, 23, 40 and 42 are formed in the stations only by being polled by a master or by internally generated
events.
**
These objects are used to mirror back values from the station to the master station, see the following reference.
***
If there is no information included about the DNP3 level, the object is supported by all implementation levels. Otherwise
the required implementation level of the communications partner is specified.
****
The following objects are always sent by the master TIM with the control code "DIRECT_OPERATE": Bin08X_S (12),
Cmd01B_S (12), Par12D_S (41), Set01W_S (41)
