Diagnostics and upkeep
7.3 SINAUT diagnostics and service tool
TIM DNP3
System Manual, 12/2015, C79000-G8976-C253-04
283
Event ID
(hex)
Detailed
event
(hex)
Meaning
F560
0090
DNP3 installation started.
F360 0091 Wrong TIM firmware loaded.
F560
0092
Installation error in the Start manager
F560
0100
Module startup: Installation error
LAN messages
F560
0101
Installation of the AMPLUS-L emulation aborted.
F560
0103
LAN communication: Error sending a message.
F560
0104
LAN communication: Error receiving a message or ID unknown.
F360
0105
LAN communication: Unknown job.
F360
0106
LAN communication: Connection could not be entered in routing table.
F360
0107
LAN communication: Connection could not be deleted in routing table.
F560
0108
LAN communication: Error in a connection SDB.
F360
0109
LAN communication: No resources available for connection.
F560
010A
LAN communication: PBC connection could not be established. Reference number unknown.
F560
010B
LAN communication: PBC connection could not be established. Reference number unknown.
F360
010C
Entering state: LAN communication: Connection down.
F260
Exiting state: LAN communication: Connection OK.
F560
010D
Entering state: LAN communication: Threat of send queue overflow for a connection.
F460 Exiting state: LAN communication: Threatening send queue overflow for a connection elimi-
nated.
F560
010E
Entering state: LAN communication: Send queue overflow for a connection.
F460
Exiting state: LAN communication: Send queue overflow for a connection eliminated.
F560
010F
Entering state: Disruption of MPI/party line interface (SPC/2) detected.
F460 Exiting state: Disruption of MPI/party line interface (SPC/2) eliminated.
F560
0110
LAN communication: Error reading the LAN SDB.
F560
0111
LAN communication: Error occurred during PBC send.
F560
0112
LAN communication: Error in SDB0 – bad MPI parameter.
F560 0113 LAN communication: A negative acknowledgment was sent.
Byte 6 of the message codes the error class (ERRCLS) and byte 7 codes the error code
(ERRCOD). For the meaning of ERRCLS and ERRCOD, see section Meaning of ERRCLS
and ERRCOD (Page 296).
F560
0114
No Ethernet SDB.
F560
0115
Ethernet SDB could not be opened.
F560
0116
Ethernet SDB with bad block ID received.
F560
0117
Error creating a socket.
F560
0118
Error linking a socket.
F560
0119
Invalid socket.
F560
011A
Error listening on a socket.
F560
011B
Ethernet port: RFC1006 has received a packet whose length exceeds the maximum.
F560
011C
Bad RFC1006 PDU header.
F560
011D
Undefined PDU received.
