12.11 Slot Description

153Digital Fault Recorder, SIMEAS R-PMU, Manual

E50417-H1076-C360-A5, Release 10.2012

12.11 Slot Description

A SIMEAS R-PMU can be equipped with a maximum of four DAU modules (1 DAU for a ZE 8/

16 and 4 DAUs for a ZE 32/64). In the Description dialog box, the channel assignment of the

individual slots is parameterized.

Figure 12-20 Description dialog



Click on a slot (1 to 4) and select the following tabs one after the other to set the individual

parameters:

 Binary channel

 Analog Channels

 Power/Frequency

 Positive/negative sequence

 DC channels (for DDAUs only)

Note

Only the tabs that are relevant for the DAU types in use are displayed.
